Submersible Slurry Pump

Short Description:

Submersible Slurry Water Pump is a vital part of the mud cleaning process. TR Solids Control is Submersible Slurry Pump manufacture.

These are heavy-duty pumps that are very beneficial for pumping all types of heavy liquids that contain solid particles.  They can be used for multiple purposes like industrial, construction, sewage, etc. people who are linked to these professions know the importance of submersible slurry pumps.

A Submersible Slurry Water Pump is a vital part of the mud cleaning process. They are primarily used as the oil drilling solids control system but can also be utilized for pumping concentrated liquids and mud. The mud is recycled through the Submersible Slurry Pump, which treats the fluid. They are made to be highly efficient and serve for an extended period. The Submersible Slurry Pump transport solid as well as liquid particles through the pipe, which are then recycled and transported to the other essential pieces of equipment that are part of the mud treatment process.

Submersible slurry pump is one kind of Centrifugal Pump. It mainly supply mud for shale shaker and decanter centrifuge from the mud pit. It transfers liquid and solid mixture. Raw material of our submersible slurry pump is rather anti-abrasive. It can transfer different hard materials. Including sand, cement, particles, shale, and so on.


Product Detail

Product Tags

Features of Submersible Slurry Pump

  • Compact design covers small space.
  • Enough rigidity in submerged parts of the shaft.
  • Submerge length can be customizable.
  • Could convey the medium containing solid particles with larger density.
  • Impeller is semi-open type.
  • No bearing between impeller and pump for less repair cost.
  • Vertical motor is installed on motor base, connecting the pump by coupling.

Submersible Slurry Pump Technical Data

Model Flow Lift Speed Motor
50YZ25-12 25m3/h 12m 1430r/min 3kw
50YZ20-18 20m3/h 18m 1430r/min 4kw
80YZ50-20B 40m3/h 16m 1440r/min 5.5kw
80YZ50-20 60m3/h 17.5m 1440r/min 7.5kw
80YZ80-20 90m3/h 22m 1460r/min 11kw
100YZ100-30A 75m3/h 30m 1470r/min 18.5kw
100YZ100-30 60m3/h 36m 1470r/min 22kw
100YZ160-38B 82m3/h 33m 1480r/min 30kw
100YZ120-60 120m3/h 40m 1480r/min 45kw
150YZ250-40A 135m3/h 35m 1480r/min 55kw
150YZ250-40B 120m3/h 28m 1480r/min 37kw
